HDPE double wall corrugated pipe making machine

Price:	160000.0~600000.0 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Shandong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: JBD-BWG400

Production Capacity: 50 sets per year

Delivery Date: 60 working days

Power: 220kw

Main extruder: SJ90/30 or SJ120/30

Means of Transport: Ocean,Land

Packing: EPE film or wooden cases

Brand Name: JBD

Capacity: 800kg/h

1.Material:PP,HDPE
2.Line speed:0.5-3m/min
3.Total power:220kw
4.Compressed air:6Bar

HDPE double wall corrugated pipe production line adopts complicated mechanic head ,double combiated machine to production to provide material and spiral writhe .The con-stitution is nice and design is special .It can guerantee the high quality of the product.The machine is controlled by the advanced PLC computer ,easy operation and steadiness.

HDPE double wall corrugated pipe making machine is configured with single screw extruder and grooved feed barrel which ensures extruding in high efficiency. Adopts vertical type forming mould with strong cooling ability, ensures stable and fast lineal speed, forms the Socket on line.

Main Technical Parameter

Name	Model	Dimension L×W×H	Total Power	Weight (kg)
Extruder	SJ90×33 SJ90×30	3780×600×3000mm 3400×560×3000mm	200kw 110kw	6000 4500
Mould Blocks ID	HDPE200	2700×Φ495mm	50 kw	2100
	HDPE225			2200
	HDPE300			2400
	HDPE400			2600
Corrugator	SBCJ500	4600×2120×2180mm	50kw	10000
Water Tank	LQB500	5100×1000×1500mm	4kw	1000
Cutter	QG6030	4252×2100×2400mm	7.5kw	3600
Unloading Bracket	JGJ500	5220×2100×830mm		230
