PP double wall corrugated pipe production line

Price: 160000.0~600000.0 USD
Payment Terms: T/T,L/C,WU
Place of Origin: Shandong, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: JBD-BWG400
Production Capacity: 50 sets per year
Delivery Date: 50 working days
Power: 220kw
Main extruder: SJ90/30 or SJ120/30
Means of Transport: Ocean,Land
Packing: EPE film or wooden cases
Brand Name: JBD
Capacity: 800kg/h
line speed: 0.5-3m/min

1.Working temperature:15-20℃
2.Line speed:0.5-3m/min
3.Total power:220kw
4.Capacity:800kg/h

Features:
1) The machine is used to produce exact small dia.double wall corrugated pipe
which material is PP, PE, PA and so on
2) Small dia. double wall corrugated pipe has such features as smooth pipe wall,
symmetrical corrugation and so on because of particular forming technics and
forming moulds
3) Widely used for cable pipe, protect pipes of car and train, supply and drainage
pipes of washer, irrigation of farm and so on.

Technique datas
Model
JBD-DBG90
JBD-DBG120
Raw material
PP
PP
Extruder
Φ90/25
Φ120/25
Range of pipe dia.
mm
Φ65-115
Φ115-175
Water consumption
L/H
4000
5000
Water pressure
Mpa
0.4-0.6
0.4-0.6
Number of mould block
pair
50
60
Whole length of mould block
mm
5180
6216
Move speed of mould block
m/min
1-12
1-8
Dimensions(L×W×H) (approx)
m
18×1.35×1.7
21×1.55×2.2
Total weight(approx)
T
6
