PVC windowsill extrusion line
Price: |
30000.0~50000.0 USD |
Payment Terms: |
T/T,L/C,WU |
Place of Origin: |
Shandong, China (Mainland) |
Product Detail
Model No.:
JBDMC-65
Production Capacity:
20 sets per year
Delivery Date:
40 working days
Use:
Others
Brand Name:
JBD
Capacity:
150-200kg/h
place of origin:
Shandong, China
Input material:
PVC+calcium carbonate+addit...
length of production line:
25m
Total power:
90kw
Air pressure:
0.6Mpa
Means of Transport:
Ocean,Land
Packing:
depends on the customers ch...
Plastic Type:
PVC
Shaft Design:
Double
Power:
90kw
condition:
new
Extruder type:
SJSZ65/132
line speed:
0.5-3m/min
Weight(approx):
13ton
Consume power:
approx 65kw
PVC door and windowsill extrusion line
1.Material:PVC+additives
2.Line speed:0.5-3m/min
3.Saves power by 30% - 40%
4.Work temperrature:0-40°C
PVC window sill profile production extrusion line mainly used to produce the PVC window sill profiles
This extrusion line adopts frequency conversion for speed regulation and super-taper twin-screw extruder with temperature controlling instrument in the screw core
PVC window sill profile production extrusion line saves power by 30% - 40%,and the rigid gear surface of the reducer can be operated continuously for a long time without trouble. Also PVC window sill extrusion line can produce steel plastic profiles by changing the wood imitation foaming profile mold, combines with one set of steel liner conveying devices.
Item | Name | Model | Qty | Details |
1 | Conical twin screw extruder | SJSZ65-132 | 1Unit | With automatic spring loader |
2 | Vacuum calibrating platform | ZK-6000 | 1Unit | |
3 | Caterpillar haul off | QY-300 | 1Unit | |
4 | Cutting unit | QG-300 | 1Unit | |
5 | stacker | FL-5000 | 1Unit | |

Description | Parameters |
Product size | customized |
Material | PVC powder+ additives |
Production line speed | 0.5-3m/min |
Max. output | 150-200kg/h |
Overall dimensions | 25m×2.5m×3m (L×W×H) |
Weight(Approx) | 13T |
Total installed power | 90kw |
Actual energy consumption power | 65kw |
Gas consumption | 0.4m3/min |
Air pressure | 0.6mpa |
Water circulating device | 0.5m3/min |
Electric condition | 380V/3P/50Hz |
Water supply | Water used for industry, no impurities, by filtrating, water pressure: 0.4mpa water temperature14~25°C |
Work environment temperature | 0-40°C |
Photos of PVC door and windowsill
